Place of Origin:
china
Model Number:
SC/APC-SC/APC Fiber Optic Patch Cord
Contact Us
Fiber Optic Patch Cable is also known as fiber optic jumper or fiber optic patch cord. Fiber Optic Patch Cable is important of optical network. They have same or different connectors which are installed on the end of fiber optic cable. Fiber optic patch cables are used in two major application areas: computer work station to outlet and patch panels or optical cross connect distribution center. The Fiber Optic Patch Cord series comes with a comprehensive collection of lengths and connectors to fulfill your demand for the deployment.
Screw-thread coupling mechanism
Ceramic ferrules
Low insertion loss, high return loss
Good in repeatability and exchangeability
100% Insertion, Return Loss, End Face and Interference inspection
Excellent mechanical endurance
High credibility and stability
Complying with Telcordia ,GR-326-Core, IEC and RoHS Standard
●Applicable to special cases that has no room for installation of Cassette type PLC splitter
●FTTX/FTTH Systems
●CATV Links
●Optical Signal Distribution
●Passive Optical Networks (PON)
●DWDM/CWDM systems
●Test equipment
●LAN/MAN/WAN network
|
Fiber Type
|
SM
|
MM
|
|
|
Optical Cable Type
|
9/125-OS1
|
62.5/125-OM1-50/125-OM2-50/125-OM3-OM4-OM5
|
|
|
Connector Type
|
FC-SC-LC-ST
|
FC-SC-LC-ST
|
|
|
Lnsertion Loss
|
≤0.3db
|
≤0.4db
|
|
|
Return Looss
|
PC≥45db APC≥60db UPC≥50db
|
≥35db
|
|
|
Mating Durability
|
≤0.2db
|
≤0.2db
|
|
|
Durability
|
≥1000times
|
≥1000times
|
|
|
Operating Temperature
|
-40℃~+85℃
|
-40℃~+85℃
|
|
|
Tensile Strength
|
70N
|
70N
|
|
|
Optical cable type, material, length and connector can be customized
|
|||
|
SX DX PVC LSZH
|
|||
|
Fiber optic cable diameter optional
|
0.9mm~2.0mm~3.0mm
|
||
|
Specification optional
|
Sarciniform/ Banding/ 12core non-jumping fiber/12
|
||
|
Can order all kinds of models, transfer, non - standard, etc
|
|||
