Place of Origin:
China
Brand Name:
YUANTONG
Certification:
CCC,IEC,ISO9001,IAF
Model Number:
Connector
Contact Us
Optical fiber connector is a device for detachable (active) connection between optical fiber and optical fiber. It precisely butts the two end faces of optical fiber, so that the light energy output from the transmitting optical fiber can be coupled to the receiving optical fiber to the maximum extent. And minimize the impact on the system due to its involvement in the optical link, which is the basic requirement of fiber optic connectors. To a certain extent, optical fiber connectors affect the reliability and performance of optical transmission systems.
Feature
1. Advanced production and testing equipment
2. Professional manufacturer, 100% tested.
3. Full compliance with ISO 9001:2008 quality management system
4. Our company has experienced professional team
5. Provide reliable solutions and satisfactory services
6. Warmly services with careful attentions.
7. Can provide your specific inquiry within 24 hours.Advanced production and testing equipment
Application
FTTx Deployments(GPON/BPON/EPON)
Cable television (CATV)
Local area networks (LAN)
Test equipment
Passive optical networks(PON)
Specification
|
Unit
|
LC,SC,FC,ST,MTRJ,MPO
|
||||
|
parameter
|
SM
|
MM
|
|||
|
PC
|
UPC
|
APC
|
PC
|
||
|
Insertion Loss
|
dB
|
≤0.2
|
≤0.2
|
≤0.2
|
≤0.2
|
|
Return Loss
|
dB
|
≥45
|
≥50
|
≥60
|
≥30
|
|
Exchangeability
|
dB
|
≤0.2
|
|||
|
Repeatability
|
dB
|
≤0.2
|
|||
|
Durability
|
Time
|
>10000
|
|||
|
Operating Temperature
|
℃
|
-40~75
|
|||
|
Storage Temperature
|
℃
|
-40~85
|
|||
